Laboratory Equipment

EQUIPMENT NAME DETAILS  FUNCTION RENTAL
Insulation Test Digital Insulation Tester Kyoritsu 3125   Measure insulation resistance
15Kv Impulse Test System  Impulse 15kV Kit Tester  Haefely Psurge 30.2  Lightning Waveform Generator
Partial Discharge Controller Partial Discharge Detectors Haefely PSZ250 System with  DDX 9101 Display  Detect partial Discharge
AC Divider AC/DC Divider  Haefely Measuring System

AC : 100kV / DC : 140kV

  Measure AC/DC voltage

(Calibrated)

AC 250 kV  250kV AC System Haefely PSZ250 System

AC : 250kV

  Measure AC voltage until 250kV & to detect partial discharge

Withstand AC until 250kV

Le Cory Oscilloscope  Oscilloscope LeCroy Wavejet  Display & capture waveform until 4 input

(Calibrated)

Digital multimeter Fluke Digital Precision Multi meter FLUKE 8845A

AC : 750v / DC : 1000v

  Measure & Display AC/DC voltage

(Calibrated)

RCZ 500 AC/DC/Impulse Divider Haefely RCZ 500   Measure AC/DC/Impulse until 500kV

Under maintenance

AC/DC Haefely 100kV Kit  AC/DC/Impulse Kit Haefely AC/DC/Impulse Kit

AC : 100kV / DC : 140kV

Impulse : 140kV

Breakdown AC/DC

Withstand AC/DC

Impulse

(Calibrated)

 Baur AC/DC HV Portable Test Set  BAUR PGK 110 HB

 Breakdown AC/DC

Withstand AC/DC

In lab only

lightning measurement system Lightning measurement system


Parallel plate antenna, LeCroy HD 4096 oscilloscope, Picoscope 5244B and computer


Measure lightning generated electric field

Vacuum Oven
Vacuum Oven


Constance

 To vacuum dry samples
Hydralic Press
Hydraulic Laboratory Press

Carver

To prepare thermoplastic samples
Furnace
Furnace

Carbolite Gero

To heat samples at high temperatures
Digital Balance
Digital Balance


OHAUS


For the purpose of weighting

AC/DC Clamp Meter
FLUKE

Model : 376

Measure current until 1000A/V
Super Mini Drill

1PK-500

Pro’sKit Drill
  AC/DC Clamp Meter FLUKE

Model : 353

Measure current until 2000A/V

(Calibrated)

DMM Probe BK Precision DC until 40kV

AC until 28kv

Ratio 1:1000

HV Prove Tektronix

Model : P6015A

Ratio 1:1000
Input Max 20kV

Under maintenance

Current Probe Tekronix

Model :

100A
  AC/DC Current Clamp FLUKE

Model : i30s

Measure current from 5mA to 30A
True-rms Multimeter with backlight and temperature FLUKE

Model : 179

Measure Temperature, Frequency and Current
Arbitrary Function Generator GW Instek

Model : AFG – 2125

Sensing & Instrumentation, Signal Processing, Test & Measurement
LCR Meter ESCORT

Model : ELC – 3131D

Measure Inductance, Capacitance and Resistance value
Current Coil WAVETEK

Model : –

Measure current

X 50 & X 10

Current Transformer Measure Current Ratio : 3000/5
Shunt Resistor EMPRO

Model : HA 100Amp 50 milivote shunt



100Amp / 50mV
Current Monitor
PEARSONTM

Model : 2877
Measure current

1 Volt/Ampere +1/-0%

Vane Anemometer
Tenma
Model : 72-6638
Measure air velocity and wind speed in air conditioning and heating systems as well as for environmental monitoring
AC Divider
BHT
Model :
Measuring system for high voltage until 150kV

(Calibrated)

DC Power Supply
Topward
Model : 6302D
Supply DC up to 30kV
Standard Resistor
Yokogawa
Model : 2792

1 ohm

100 ohm

1k ohm

10k ohm

Digital Phosphor Oscilloscope
Tektronix
Model : DPO 3014
100Mhz

2.5 GS/s

Single Channel Arbitrary / Function Generator
Tektronix
Model : AFG3021c
250MS/s

25Mhz

Terrametter
ABEM
Model : SAS 300c
Measuring earthing resistance
Electrochemical Measuring System Gamry Interface 1000
PD Calibrator Haefely

Type 145

Calibrate PD system before measuring PD for testing (Calibrated)

Under maintenance

Oil Test Set Meter Megger OTS60SX Oil Dielectric testing up to 60kV

(Calibrated)
